ReamMeister – Hub Wheel – AH725
IMPROVED PRODUCTIVITY & TOOL LIFE
ReamMeister, despite the use of long overhang setup, provided stable machining with no chatter. As a result, Productivity was increased by 12 times and tool life extended by 1.2 times.
Share
| Industry | Heavy |
|---|---|
| Component | Hub wheel |
| Material ISO code |
 P - Steel |
| Work material | SCM435 |
| Machine(spindle type) | Horizontal Machining Center Large(#50,HSK100) |
| Tool family | Holemaking |
| Tool category | Reaming |
| Product name | ReamMeister |
| TSR No. | 1647D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TRM-T6-R16-8 | Brazed reamer |
| Head | HRM-16.000-BL-T6 | φ16.0, z=6 |
| Grade | AH725 | PVD, P20 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 16 | 16 |
| Hole tolerance grade | H7 | H7 |
| Pilot hole diameter (mm) | 15.8 | 15.8 |
| Hole depth H (mm) | 18 | 18 |
| Cutting speed V/c (mm/min) | 60 | 15 |
| Feed f (mm/rev) | 0.7 | 0.23 |
| Feed speed Vf (mm/min) | 836 | 70 |
| Coolant | Internal coolant | Internal coolant |
