DoFeed Wiper – Automotive Part Mold – AH725
IMPROVED PRODUCTIVITY
High Productivity
- Conventionally, DoFeed was used only for Roughing and scooping the material from the mold and an indexable blade type endmill is used for semi-finishing process. In this case,DoFeed wiper insert provided high productivity and good surface roughness for mold facemilling, which eliminated semi finishing process.
Share
![DoFeed](https://tsr.tungaloy.com/wp-content/uploads/products/tsr_product_dofeed.jpg)
Industry | Die & Mold |
---|---|
Component | Automotive part |
Material ISO code |
|
Work material | X40CrmoV5-1 |
Machine(spindle type) | Vertical Machining Center |
Tool family | Milling |
Tool category | Face milling |
Product name | DoFeed |
TSR No. | 394M |
![Automotive part](https://tsr.tungaloy.com/wp-content/uploads/work/work_394M.jpg)
Tool
Tungaloy | Competitor | |
---|---|---|
Body | TXN06R080M31.7-08 | Ball type indexable endmill |
Effective number of teeth | 8 | 2 |
Cutting diameter | 80 | 32 |
Insert | LNMU06X5ZER-MJ x7 LNGU06X5ZER-W x1 | Ball type insert |
Number of cutting edges | 8 | 2 |
Grade | AH725 | PVD |
Cutting conditions
Tungaloy | Competitor | |
---|---|---|
Cutting speed V/c (mm/min) | 151 | 80 |
Feed per tooth f/z (mm/t) | 0.11 | 0.1 |
Feed speed Vf (mm/min) | 529 | 160 |
Depth of cut ap (mm) | 0.1 | 0.1 |
Width of cut ae (mm) | 60 | 32 |
Coolant | Air blow | Air blow |
