TungMeister – Base plate – AH715
IMPROVED PRODUCTIVITY AND TOOL LIFE
TungMeister, combined with built-up edge resistant AH715 grade, eliminated built-up edge and provided double tool life.
Share
| Industry | Engineering |
|---|---|
| Component | Base plate |
| Material ISO code |
 M - Stainless steel |
| Work material | SUS430 |
| Machine(spindle type) | Vertical Machining Center Middle(#40,HSK63) |
| Tool family | Milling |
| Tool category | Chamfering |
| Product name | TungMeister |
| TSR No. | 5109M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | VSSD10L075S06-S | |
| Number of teeth | 2 | 2 |
| Cutting diameter | 10 | 10 |
| Insert | VCP100L09.0A45-02S06 | φ10 Solid chamfering tool |
| Number of cutting edges | 1 | 1 |
| Grade | AH715 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (mm/min) | 22 | 12 |
| Feed per tooth f/z (mm/t) | 0.04 | 0.04 |
| Feed speed Vf (mm/min) | 55 | 30 |
| Depth of cut ap (mm) | 2 | 2 |
| Width of cut ae (mm) | 2 | 2 |
| Coolant | Wet(External) | Wet(External) |
