NTK Ceramic – Machine Skeleton – SX6
NTK Ceramic - Machine Skeleton - SX6
Compared with the current process, machining efficiency increased by 7.5 times.
In addition, chips were finer than with wet machining, and dry machining made cleaning easier, resulting in improved operational efficiency.
Tool life, measured by machining distance, was also extended from 147 m to 275 m.
Share
| Industry | Machine production |
|---|---|
| Component | Machine Skeleton |
| Material ISO code |
 K - Cast iron |
| Work material | FC250 |
| Machine(spindle type) | CNC Lathe |
| Tool family | Milling |
| Tool category | Face milling |
| Product name | SX6 Ceramic Insert |
| TSR No. | 5570M |
Tool
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Body | JFDX125-75-12R | φ125ｘ8 tooth |
| Insert | SNGF120412T01025RC-CM | SXMU1606 |
| Grade | SX6 | Carbide |
Cutting conditions
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 1000 | 150 |
| Feed per tooth f/z (mm/t) | 0.15 | 0.2 |
| Feed speed Vf (mm/min) | 4586 | 611 |
| Depth of cut ap (mm) | 2.0 | 2.0 |
| Coolant | DRY | WET |
