DoOcto – Pump Housing – T1215
IMPROVED PRODUCTIVITY AND TOOL LIFE
High productivity
- DoOcto’s tough cutting edge allows the operation at high feed rate and large DOC without breakage even in machining of alloyed cast iron.
Long tool life
- T1215 has good wear resistance because of thick CVD coating and delivers long tool life even under higher cutting conditions.
Share
| Industry | Engineering |
|---|---|
| Component | Pump Housing |
| Material ISO code |
 K - Cast iron |
| Work material | Alloyed Cast Iron |
| Machine(spindle type) | Horizontal Machining Center |
| Tool family | Milling |
| Tool category | Face milling |
| Product name | DoOcto |
| TSR No. | 451M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TAN07R400U015A07 | Face mill |
| Effective number of teeth | 7 | 7 |
| Cutting diameter | 101.6 | 101.6 |
| Insert | ONMU0705ANPN-MJ | Square type positve insert |
| Number of cutting edges | 16 | 4 |
| Grade | T1215 | CVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (mm/min) | 366 | 351 |
| Feed per tooth f/z (mm/t) | 0.25 | 0.2 |
| Feed speed Vf (mm/min) | 2036 | 1561 |
| Depth of cut ap (mm) | 2.5 | 2 |
| Width of cut ae (mm) | 76.2 | 76.2 |
| Coolant | Dry | Dry |
