ReamMeister -Spindle chuck- AH725
IMPROVED PRODUCTIVITY
The conventional product used external coolant supply, which frequently caused chip entanglement. The internally cooled ReamMeister enabled approximately 10 times higher machining efficiency and improved chip breaking by applying high-speed, high-feed cutting conditions.
Share
| Industry | Machine production |
|---|---|
| Component | Spindle chuck |
| Material ISO code |
 P - Steel |
| Work material | SCM420 |
| Machine(spindle type) | Horizontal Machining Center Middle(#40,HSK63) |
| Tool family | Holemaking |
| Tool category | Reaming |
| Product name | ReamMeister |
| TSR No. | 5629D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TRM-T8-R20-8 | Solid carbide |
| Head | HRM-24.000-AS-T8 AH725 | |
| Grade | AH725 | PVD, P10 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 24 | 24 |
| Hole tolerance grade | H7 | H7 |
| Pilot hole diameter (mm) | 23.8 | 23.8 |
| Hole depth H (mm) | 150 | 150 |
| Cutting speed V/c (m/min) | 100 | 50 |
| Feed f (mm/rev) | 0.96 | 0.2 |
| Feed speed Vf (mm/min) | 1273 | 133 |
| Coolant | Emulsion, Internal | Emulsion, External |
