TungSix-Drill Inconel625 – Flange – AH6030
TOOL LIFE IN DRILLING OF INCONEL FLANGE
Smooth machining: TungSix-Drill enables smooth machining even in Super alloy drilling. Economical: TungSix-Drill is more economical: the number of cutting edges is higher by 1.5 times. TungSix-Drill decreases insert consumption in machining of short tool life materials like super alloy.
Share
| Industry | Power Generation |
|---|---|
| Component | Flange |
| Material ISO code |
 S - Super-alloys and titanium |
| Work material | Inconel 625 |
| Machine(spindle type) | Vertical Machining Center |
| Tool family | Holemaking |
| Tool category | Drilling |
| Product name | TungSix-Drill |
| TSR No. | 200D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TDS350F40-3 | ø35-3D |
| Insert | WWMU09X510R-DS | Square type insert |
| Grade | AH6030 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 35 | 35 |
| Hole depth H (mm) | 60 | 60 |
| Cutting speed V/c (m/min) | 50 | 50 |
| Feed f (mm/rev) | 0.11 | 0.11 |
| Feed speed Vf (mm/min) | 22 | 22 |
| Coolant | Water soluble(Internal) | Water soluble(Internal) |
