DoFeed – Discharge Casing – AH3225
IMPROVED PRODUCTIVITY
High productivity
– DoFeed provides 1.4times higher productivity than the competitor, because it allows higher cutting speed with a large number of cutting teeth.
Long tool life
– AH3035 with excellent thermal shock resistance inhibits fracture caused by thermal crack, resulting in 1.5 times longer tool life.
Share
| Industry | Power Generation |
|---|---|
| Component | Discharge Casing |
| Material ISO code |
 M - Stainless steel |
| Work material | Duplex stainless steel |
| Machine(spindle type) | Horizontal Machining Center |
| Tool family | Milling |
| Tool category | Face milling |
| Product name | DoFeed |
| TSR No. | 370M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TXN06R200M47.6-12 | High feed cutter |
| Effective number of teeth | 12 | 10 |
| Cutting diameter | 200 | 200 |
| Insert | LNMU06X5ZER-MJ | Square type positive insert |
| Number of cutting edges | 4 | 4 |
| Grade | AH3225 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (mm/min) | 75 | 62 |
| Feed per tooth f/z (mm/t) | 0.97 | 1 |
| Feed speed Vf (mm/min) | 1400 | 1000 |
| Depth of cut ap (mm) | 0.5 | 0.5 |
| Width of cut ae (mm) | 160 | 160 |
| Coolant | Dry | Dry |
