Tung-Tri – Turbo Housing – AH3135
IMPROVED PRODUCTIVITY AND TOOL LIFE
High productivity
- While the competitor couldn’t increase the feed rate because of chipping, Tung-Tri achieved triple feed rate without chipping due to its tougher edge and grade.
Improved tool life
- Thanks to the good wear and welding resistance of grade AH3135, Tung-Tri’s tool life increased by 30% compared to the competitor.
Share
| Industry | Automotive |
|---|---|
| Component | Turbo Housing |
| Material ISO code |
 K - Cast iron |
| Work material | Hi-Si FCD |
| Machine(spindle type) | Multi-axis Lathe |
| Tool family | Milling |
| Tool category | Face milling |
| Product name | Tung-Tri |
| TSR No. | 368M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | EPA10R032M32.0-03N | Shoulder cutter |
| Effective number of teeth | 3 | 5 |
| Cutting diameter | 32 | 32 |
| Insert | TOMT100404PDER-MJ | 2 corner positive insert |
| Number of cutting edges | 3 | 2 |
| Grade | AH3135 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (mm/min) | 200 | 150 |
| Feed per tooth f/z (mm/t) | 0.15 | 0.05 |
| Feed speed Vf (mm/min) | 895 | 373 |
| Depth of cut ap (mm) | 4 | 4 |
| Width of cut ae (mm) | 32 | 32 |
| Coolant | Dry | Dry |
