DoPent – Steering Knuckle – AH120
IMPROVED PRODUCTIVITY
High productivity
– DoPent achieves high productivity without chattering even on low rigid machine components. This is because of the low thrust force due to 70 deg approach angle and sharp rake angle.
Share
| Industry | Automotive |
|---|---|
| Component | Steering Knuckle |
| Material ISO code |
 K - Cast iron |
| Work material | Ductile cast iron |
| Machine(spindle type) | Vertical Machining Center |
| Tool family | Milling |
| Tool category | Face milling |
| Product name | DoPent |
| TSR No. | 364M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TEN09R100M31.7-08 | Face mill cutter |
| Effective number of teeth | 8 | 7 |
| Cutting diameter | 100 | 100 |
| Insert | PNCU0905GNER-MJ | SEEN1203 |
| Number of cutting edges | 10 | 4 |
| Grade | AH120 | CVD K20 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (mm/min) | 165 | 165 |
| Feed per tooth f/z (mm/t) | 0.14 | 0.14 |
| Feed speed Vf (mm/min) | 588 | 515 |
| Depth of cut ap (mm) | 3 | 3 |
| Width of cut ae (mm) | 60 | 60 |
| Coolant | Wet (Internal) | Wet (Internal) |
