TungSix-Drill – Connecting Rod – AH9030
IMPROVED TOOL LIFE
Combined operation
- Drill with chamfering enables drilling a chamfered hole in one process, reducing process time.
Economical
- TungSix-Drill is more economical due to 1.5 times number of cutting edges and 1.6 times longer tool life per corner. Effective: 2.4 times /insert.
Tool Life
- Drilling length: 2.4 times.
Share
| Industry | Automotive |
|---|---|
| Component | Connecting Rod |
| Material ISO code |
 P - Steel |
| Work material | C55 |
| Machine(spindle type) | Vertical Machining Center Middle(#40,HSK63) |
| Tool family | Holemaking |
| Tool category | Drilling |
| Product name | TungSix-Drill |
| TSR No. | 191D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | Special Φ30 TDS with 1mm chamfering | Special tool |
| Insert | WWMU08X408R-DJ | Square type insert |
| Grade | AH9030 | PVD |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Tool life (m/insert) | 36 | 15 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 30 | 30 |
| Hole depth H (mm) | 30 | 30 |
| Cutting speed V/c (mm/min) | 193 | 193 |
| Feed f (mm/rev) | 0.12 | 0.12 |
| Feed speed Vf (mm/min) | 255 | 255 |
| Coolant | Water soluble (External) | Water soluble (External) |
