TungSix-Drill – Flange – AH6030
IMPROVED TOOL LIFE
Economical
- TungSix-Drill is more economical: the number of cutting edges is higher by 1.5 times and the tool life per corner is longer by 2 times. TungSix-Drill decreases insert consumption in machining of short tool life materials like super alloy.
Share
| Industry | Power Generation |
|---|---|
| Component | Flange |
| Material ISO code |
 S - Super-alloys and titanium |
| Work material | Inconel 625 |
| Machine(spindle type) | Vertical Machining Center |
| Tool family | Holemaking |
| Tool category | Drilling |
| Product name | TungSix-Drill |
| TSR No. | 187D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TDS350F40-3 | Indexable drill |
| Insert | WWMU09X510R-DS | Square type insert |
| Grade | AH6030 | PVD |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Tool life (m/insert) | 3 | 1 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 35 | 35 |
| Hole depth H (mm) | 60 | 60 |
| Cutting speed V/c (mm/min) | 40 | 40 |
| Feed f (mm/rev) | 0.06 | 0.06 |
| Feed speed Vf (mm/min) | 22 | 22 |
| Coolant | Water soluble(Internal) | Water soluble(Internal) |
