TungSix-Drill – Valve – AH9030
IMPROVED TOOL LIFE
Economical: TungSix-Drill is more economical due to 1.5 times higher number of cutting edges and improving tool life per edge.
Stable machining: TungSix-Drill operates without any vibration and enables excellent chip control.
Share
![TungSix-Drill](https://tsr.tungaloy.com/wp-content/uploads/products/tsr_product_tungsix-drill.jpg)
Industry | Oil & Gas |
---|---|
Component | Valve |
Material ISO code |
|
Work material | 39NiCrMo5 |
Machine(spindle type) | Horizontal Machining Center |
Tool family | Holemaking |
Tool category | Drilling |
Product name | TungSix-Drill |
TSR No. | 177D |
![Valve](https://tsr.tungaloy.com/wp-content/uploads/work/work_177D.jpg)
Tool
Tungaloy | Competitor | |
---|---|---|
Body | TDS280F32-2 | Indexable drill |
Insert | WWMU08X408R-DJ | Square type insert |
Grade | AH9030 | PVD |
Cutting conditions
Tungaloy | Competitor | |
---|---|---|
Tool diameter DC (mm) | 28 | 28 |
Hole depth H (mm) | 50 | 50 |
Cutting speed V/c (mm/min) | 180 | 180 |
Feed f (mm/rev) | 0.18 | 0.18 |
Feed speed Vf (mm/min) | 369 | 369 |
Coolant | Water soluble(Internal) | Water soluble(Internal) |
