DeepTriDrill – Gas burner parts – TRLG

IMPROVED PRODUCITIVTY AND HOLE QUALITY

Drill Productivity Three times compared to traditional brazed drills.
DeepTriDrill delivered clean holes with minimal cutting noise ans short chips. Increased feed to 0.03 mm/rev resulting in a feed rate three times better than the previous brazed drill. Chip evacuation was greatly improved.
This advancement not only ensures cleaner holes and quieter operations but also enhances the overall efficiency and satisfaction in drilling SUS309S material for gas burner parts.

DeepTri-Drill
産業 一般機械部品
加工部品 Gas Burner Part
ISOコード M - ステンレスM - ステンレス
被削材 SUS309S
工作機械(スピンドルタイプ) ガンドリルマシン
加工分類 穴あけ
加工形態 深穴加工
製品名 DeepTri-Drill
TSR No. 5165D
Gas Burner Part

使用工具

タンガロイ 他社品
ボディ TRLG13.00X100-U4 brazed gun-drill
インサート LOGT060204R-NDJ AH9130 brazed
材種 AH9130 coated carbide

切削条件

タンガロイ 他社品
穴径 DC (mm) 13 13
穴深さ H (mm) 205 205
切削速度 V/c (mm/min) 40 40
送り f (mm/rev) 0.01 0.03
送り速度 Vf (mm/min) 10 29
切削油 oil oil

試験結果

ProductivityImproved 3 times
