TinyMiniTurn Indexable type – Valve Body Seat – SH725
IMPROVED CHIP CONTROL & TOOL LIFE
NEW 4 coolant holes TinyMiniTurn sleeve and EPGT..JS geometry insert enabled better chip control. As the result, solved the chip jamming in all 3 type of material. In addition, tool life was increased 1.5 times with 1.1 times productivity increase.
Share
![TinyMini-Turn](https://tsr.tungaloy.com/wp-content/uploads/products/tsr_product_tinymini-turn.jpg)
Industry | Miniature |
---|---|
Component | Valve body seat |
Material ISO code |
|
Work material | SUM22L |
Machine(spindle type) | Swiss Lathe |
Tool family | Turning |
Tool category | Internal turning |
Product name | TinyMini-Turn |
TSR No. | 1667T |
![Valve body seat](https://tsr.tungaloy.com/wp-content/uploads/work/work_1667T.jpg)
Tool
Tungaloy | Competitor | |
---|---|---|
Holder | E07060-SEXPR04-5 | |
Sleeve | JBBS20-7-L100C-4N | |
Insert | EPGT040101F-JS | Solid boring bar |
Grade | SH725 | PVD |
Cutting conditions
Tungaloy | Competitor | |
---|---|---|
Cutting speed V/c (mm/min) | 55 | 50 |
Feed f (mm/rev) | 0.01 | 0.01 |
Depth of cut ap (mm) | 0.05 | 0.05 |
Coolant | Internal supply | External supply |
