ModuMiniTurn – Ball Screw Shaft – SH725
REDUCTION OF MACHINE DOWNTIME
ModuMiniTurn modular tool system made TetraMiniCut threading insert changes quick and easy, thanks to the unique head-shank coupling. Single screw release function allowed a quick release and assembly of modular heads, while the holders remaining in the tool post. The tool design allowed a key wrench to easily access to the release screw, eliminating the concern for the interference with the adjacent tools. As the result, insert change time was reduced by 60%.
Share
![ModuMini-Turn](https://tsr.tungaloy.com/wp-content/uploads/products/tsr_product_modumini-turn.jpg)
Industry | Miniature |
---|---|
Component | Ball Screw Shaft |
Material ISO code |
|
Work material | S55C |
Machine(spindle type) | Swiss Lathe |
Tool family | Turning |
Tool category | External threading |
Product name | ModuMini-Turn |
TSR No. | 1608T |
![Ball Screw Shaft](https://tsr.tungaloy.com/wp-content/uploads/work/work_1608T.jpg)
Tool
Tungaloy | Competitor | |
---|---|---|
Holder | QC12-STCR18 | 12x12 square holder |
Shank | QC-1212X | |
Insert | TCT18FR-60A-005 | Lay down |
Edges par insert | 4 | 3 |
Grade | SH725 | PVD |
Cutting conditions
Tungaloy | Competitor | |
---|---|---|
Cutting speed V/c (mm/min) | 60 | 60 |
Insert exchange time (seconds) | 50 | 120 |
Coolant | Wet | Wet |
