TungTap -Brake disc- AB070
IMPROVED TOOL LIFE
Conventional taps experienced wear and chipping due to chip clogging, resulting in short tool life. The AB070 grade, which offers excellent heat resistance, suppresses wear, while an edge treatment optimized for cast iron machining helps prevent chipping. As a result, tool life was extended
Share
| Industry | Automotive |
|---|---|
| Component | Brake Disk |
| Material ISO code |
 K - Cast iron |
| Work material | FC250/GG25/EN-GJL-250 |
| Machine(spindle type) | Multi-Tasking Machine |
| Tool family | Holemaking |
| Tool category | Tapping |
| Product name | TungTap |
| TSR No. | 5646D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TP-M8X1.25-DNBG AB070 | HSS tap |
| Grade | AB070 | HSSE+PVD |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Number of workpieces (pcs/insert) | 4000 | 3000 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 8 | 8 |
| Pilot hole diameter (mm) | 6.8 | 6.8 |
| Hole depth H (mm) | 6 | 6 |
| Cutting speed V/c (m/min) | 30 | 30 |
| Feed f (mm/rev) | 1.25 | 1.25 |
| Feed speed Vf (mm/min) | 1500 | 1500 |
| Coolant | Emulsion, External | Emulsion, External |
