NTK Ceramic – Disk -JX3
NTK Ceramic - Disk -JX3
With the current insert, wear resistance was insufficient, but JX3 provided improved wear resistance, extending tool life by 1.5 times.
The cutting speed also increased by 1.5 times, and the reduced insert replacement frequency and setup time led to improved productivity.
Share
| Industry | Aerospace |
|---|---|
| Component | Disk |
| Material ISO code |
 S - Super-alloys and titanium |
| Work material | Ni base alloy |
| Machine(spindle type) | CNC Lathe |
| Tool family | Turning |
| Tool category | External & Face turning |
| Product name | JX3 Ceramic Insert |
| TSR No. | 5528T |
Tool
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Insert | RNGN120700T01020 | RNGN120700T01020 |
| Grade | JX3 | Ceramic |
Tool life
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Tool life (pcs/edge) | 0.45 | 0.3 |
Cutting conditions
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 330 | 220 |
| Feed f (mm/rev) | 0.15 | 0.15 |
| Depth of cut ap (mm) | 1.5 | 1.5 |
| Number of pass | 1 | 1 |
| Coolant | WET | WET |
