NTK Ceramic – Wheel Hub – SX6
NTK Ceramic - Wheel Hub - SX6
SX6 is superior tool life during high-speed machining due to its wear resistance.
Compared with competing products, cutting speed was doubled and tool life was extended twice.
Share
| Industry | Automotive |
|---|---|
| Component | Wheel hub |
| Material ISO code |
 K - Cast iron |
| Work material | FCD400 |
| Machine(spindle type) | CNC Lathe |
| Tool family | Turning |
| Tool category | Internal turning |
| Product name | SX6 Ceramic Insert |
| TSR No. | 5522T |
Tool
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Insert | CNGA120412T02020 | CNMG120412 |
| Grade | SX6 | Coated Carbide |
Tool life
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Tool life (pcs/edge) | 20 | 10 |
Cutting conditions
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 700 | 350 |
| Feed f (mm/rev) | 0.35 | 0.35 |
| Depth of cut ap (mm) | 2 | 2 |
| Number of pass | 2 | 2 |
| Coolant | DRY | DRY |
