TungDrillTwisted – Shoe for Earthmoving Equipment – AH6030
IMPROVED TOOL LIFE
AH6030 prevents chipping thanks to well-balanced wear and fracture resistance. Tool life is improved by 2 times and productivity by 1.7 times compared with the competitor.
Share
| Industry | Heavy |
|---|---|
| Component | Shoe for Earthmoving Equipment |
| Material ISO code |
 P - Steel |
| Work material | SMnB-3 |
| Machine(spindle type) | Vertical Machining Center |
| Tool family | Holemaking |
| Tool category | Drilling |
| Product name | TungDrillTwisted |
| TSR No. | 528D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TDX160F20-2 | Head changeble drill |
| Insert | XPMT050204R-DJ | Drilling head |
| Grade | AH6030 | PVD |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Number of workpieces (pcs/insert) | 400 | 150 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 16 | 16 |
| Hole depth H (mm) | 16 | 16 |
| Cutting speed V/c (mm/min) | 100 | 50 |
| Feed f (mm/rev) | 0.15 | 0.18 |
| Feed speed Vf (mm/min) | 300 | 180 |
| Coolant | Internal | Internal |
