TungDrillTwisted – Shaft – AH6030
IMPROVED TOOL LIFE
AH6030 provides stable and longer tool life thanks to excellent wear resistance. Tool life is extended by 2.6 times compared with the competitor.
Share
| Industry | Automotive |
|---|---|
| Component | Shaft |
| Material ISO code |
 M - Stainless steel |
| Work material | X2CrNiMo17-12-2 |
| Machine(spindle type) | CNC Lathe |
| Tool family | Holemaking |
| Tool category | Drilling |
| Product name | TungDrillTwisted |
| TSR No. | 527D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TDX190F25-3 | Indexable drill |
| Insert | XPMT06X308R-DJ | W type insert |
| Grade | AH6030 | PVD |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Number of workpieces (pcs/insert) | 800 | 300 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 19 | 19 |
| Hole depth H (mm) | 33 | 33 |
| Cutting speed V/c (mm/min) | 150 | 150 |
| Feed f (mm/rev) | 0.12 | 0.12 |
| Feed speed Vf (mm/min) | 310 | 310 |
| Coolant | Wet (Internal) | Wet (Internal) |
