TetraForce-Cut – Shaft – AH725
IMPROVED PRODUCTIVITY & TOOL LIFE
Good chip evacuation
- The current item had trouble with chip evacuation because of a ground chip breaker. Also, the chip breaker often scratched the workpiece, producing more defects.
- TetraForce-Cut controls chipping using a 3-dimensional chipbreaker without wrapping around the tool or workpiece. As a result, TetraForce-Cut perfectly machined with no defective products.
Highly stable machining
- The combination of a sharp chipbreaker and AH725 with high wear resistance provides stable and long tool life.
Share
| Industry | Automotive |
|---|---|
| Component | Shaft |
| Material ISO code |
 P - Steel |
| Work material | C45 |
| Machine(spindle type) | CNC Lathe |
| Tool family | Grooving |
| Tool category | Parting off |
| Product name | TetraForce-Cut |
| TSR No. | 252T |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Holder | STCL1212-27 | 12X12 shank |
| Insert | TCS27-150-020 | 1,5mm width insert |
| Cutting width | 1.5 mm | 1.5 mm |
| Grade | AH725 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (mm/min) | 60 | 60 |
| Feed f (mm/rev) | 0.08 | 0.08 |
| Coolant | Water soluble | Water soluble |
