TungSix-Drill – Food Machine – AH9030
IMPROVED TOOL LIFE
Economical
- TungSix-Drill is more economical 50% higher number of cutting edges and improving tool life per edge.
Higher productivity
- TungSix-Drill can be used at higher cutting speed and feed, thanks to the thicker cross section of the insert.
Share
| Industry | Engineering |
|---|---|
| Component | Food Machine |
| Material ISO code |
 P - Steel |
| Work material | 100Cr6 |
| Machine(spindle type) | Vertical Machining Center |
| Tool family | Holemaking |
| Tool category | Drilling |
| Product name | TungSix-Drill |
| TSR No. | 178D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TDS390F40-2 | Indexable drill |
| Insert | WWMU11X512R-DJ | Square type insert |
| Grade | AH9030 | PVD |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Tool life (m/insert) | 15.6 | 6.8 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 39 | 39 |
| Hole depth H (mm) | 55 | 55 |
| Cutting speed V/c (mm/min) | 180 | 160 |
| Feed f (mm/rev) | 0.1 | 0.08 |
| Feed speed Vf (mm/min) | 147 | 105 |
| Coolant | Water soluble(Internal) | Water soluble(Internal) |
