ShredMeister, Conveyor rail groove, AH725
IMPROVED TOOLLIFE
The three-flute ShredMeister provides excellent chip evacuation during slotting operations, enabling stable machining.
Compared to competitors, it achieved 1.3 times higher machining efficiency and 2.1 times longer tool life.
Share
| Industry | Machine Tool Builders |
|---|---|
| Component | Conveying device |
| Material ISO code |
 P - Steel |
| Work material | SCM420 |
| Machine(spindle type) | Vertical Machining Center Small(#30,HSK40) |
| Tool family | Milling |
| Tool category | Slot milling |
| Product name | ShredMeister |
| TSR No. | 5454M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TERF070E3-20C08-63 | |
| Number of teeth | 3 | 4 |
| Cutting diameter | 7 | 7 |
| Grade | AH725 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 120 | 90 |
| Feed per tooth f/z (mm/t) | 0.05 | 0.04 |
| Feed speed Vf (mm/min) | 819 | 655 |
| Depth of cut ap (mm) | 5 | 5 |
| Width of cut ae (mm) | 7 | 7 |
| Coolant | External | External |
