DoTriple-Mill – Front axle – T3225
IMPROVED PRODUCTIVITY & TOOL LIFE
Featuring improved wear resistance, DoTriple-Mill’s T3225 grade provided 1.6 times longer tool life with high cutting speed. In addition, the productivity was increased by 1.3 times over the competitor.
Share
| Industry | Automotive |
|---|---|
| Component | Front axle |
| Material ISO code |
 P - Steel |
| Work material | S48C |
| Machine(spindle type) | Vertical Machining Center |
| Tool family | Milling |
| Tool category | Face milling |
| Product name | DoTriple-Mill |
| TSR No. | 1689M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TASN13J160B50.8R12 | Indexable face mill |
| Effective number of teeth | 12 | 10 |
| Cutting diameter | 160 | 160 |
| Insert | SNMU1307ANEN-MJ | Negative Square insert |
| Number of cutting edges | 8 | 8 |
| Grade | T3225 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 250 | 200 |
| Feed per tooth f/z (mm/t) | 0.1 | 0.12 |
| Feed speed Vf (mm/min) | 600 | 477 |
| Depth of cut ap (mm) | 3 | 3 |
| Width of cut ae (mm) | 100 | 100 |
| Coolant | Air blow | Air blow |
