DrillForceMeister – Gear – AH9130
IMPROVE PRODUCTIVITY
The combination of DrillForceMeister which has high-rigidity clamping system with screw and super stable SMC head achieved 4.3 times better productivity.
Share
| Industry | Heavy |
|---|---|
| Component | Gear |
| Material ISO code |
 P - Steel |
| Work material | SCM440/42CrMo4 |
| Machine(spindle type) | CNC Lathe |
| Tool family | Holemaking |
| Tool category | Drilling |
| Product name | DrillForce-Meister |
| TSR No. | 5245D |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TIS320F40-5 | Indexable drill |
| Head | SMP320 AH9130 | Insert |
| Grade | AH9130 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Tool diameter DC (mm) | 32 | 32 |
| Hole depth H (mm) | 120 | 120 |
| Cutting speed V/c (m/min) | 120 | 100 |
| Feed f (mm/rev) | 0.18 | 0.05 |
| Feed speed Vf (mm/min) | 215 | 50 |
| Coolant | Internal Coolant | Internal Coolant |
