ISO-EcoTurn – Shaft Parts – T9225
COST REDUCTION
Extended tool life
- T9225 grade with excellent wear and fracture resistance extends tool life by 1.4 times compared to the competitor that often gets fracture.
Economical advantage
- The EcoTurn inserts provide the same level of cutting performance as the regular-sized inserts in machining with up to 3mm depth of cut. Compared to the regular-sized inserts, the EcoTurn inserts are dimensionally smaller, which helps significant cost reduction.
Share
| Industry | Automotive |
|---|---|
| Component | Shaft Parts |
| Material ISO code |
 P - Steel |
| Work material | C30/S30CV |
| Machine(spindle type) | CNC Lathe |
| Tool family | Turning |
| Tool category | External turning |
| Product name | ISO-EcoTurn |
| TSR No. | 408T |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Holder | AWLNR2525M0604-A | AWLNR2525M0604-A |
| Insert | WNMG060408E-TM | WNMG080408-Medium chip breaker |
| Grade | T9225 | CVD(P15) |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Tool life (pcs/edge) | 280 | 200 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 190 | 190 |
| Feed f (mm/rev) | 0.25 | 0.25 |
| Depth of cut ap (mm) | 2.5 | 2.5 |
| Coolant | Water soluble | Water soluble |
