TetraForce-Cut – Bone Screw – AH725
IMPROVED TOOL LIFE
Sharp cutting edge
- The current tool, with a width of 2.2mm and a small negative land on the cutting edge, was broken at a tool life of 1500pcs/c due to the increase in temperature caused by the increase in cutting force. TetraForce-Cut has a very sharp chipbreaker, making it suitable for titanium alloy machining.
Excellent wear resistance
- By combining with AH725, which has superior wear resistance and fracture resistance, TetraForce-Cut achieved a longer tool life of 1.3 times.
Share
| Industry | Medical |
|---|---|
| Component | Bone Screw |
| Material ISO code |
 S - Super-alloys and titanium |
| Work material | Ti-6Al-4V |
| Machine(spindle type) | Dedicated Machine |
| Tool family | Grooving |
| Tool category | Parting off |
| Product name | TetraForce-Cut |
| TSR No. | 212T |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Insert | TCS27-150-6R | 2 corner insert |
| Edges par insert | 4 | 2 |
| Cutting width | 1.5 | 2.2 |
| Grade | AH725 | PVD |
Tool life
| Tungaloy | Competitor | |
|---|---|---|
| Tool life (pcs/edge) | 2000 | 1500 |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | ～50 | ～50 |
| Feed f (mm/rev) | 0.03 | 0.03 |
| Coolant | Water soluble | Water soluble |
