FinishMeister- Piston- AH725
IMPROVED PRODUCTIVITY
In turn-milling of the outer periphery of pistons, two end mills were previously used for roughing and finishing. With FinishMeister, tool consolidation was achieved, and roughing efficiency became three times higher than before. Tool life remained equivalent to conventional tools, allowing for trouble-free operation and adoption on the mass production line.
Share
| Industry | Shipbuilding industry |
|---|---|
| Component | Piston Ring |
| Material ISO code |
 K - Cast iron |
| Work material | Cast iron nodular |
| Machine(spindle type) | Horizontal Machining Center Large(#50,HSK100) |
| Tool family | Milling |
| Tool category | Shoulder milling |
| Product name | FinishMeister |
| TSR No. | 5423M |
Tool
| Tungaloy | Competitor | |
|---|---|---|
| Body | TEFS250E44-52C25CF121 | |
| Number of teeth | 4 | 4 |
| Cutting diameter | 25 | 25 |
| Overhang (mm) | 55 | 55 |
| Grade | AH725 | PVD |
Cutting conditions
| Tungaloy | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 120 | 79 |
| Feed per tooth f/z (mm/t) | 0.07 | 0.07 |
| Feed speed Vf (mm/min) | 428 | 282 |
| Depth of cut ap (mm) | 30 | 30 |
| Width of cut ae (mm) | 6 | 3 |
| Coolant | External | External |
