NTK Ceramic – Connecting Rod – SX7
NTK Ceramic – Connecting Rod – SX7
HC7 has a high hot hardness and low plasticity at high temperatures, making it ideal for finishing of hardened materials. By replacing CBN, tool costs can be significantly reduced. As a results, HC7 achieved double the tool life compared to competing products and also achieved cost reduction.
Share
| Industry | Construction |
|---|---|
| Component | Connecting Rod |
| Material ISO code |
 H - Hardened material |
| Machine(spindle type) | CNC Lathe |
| Tool family | Turning |
| Tool category | External turning |
| Product name | HC7 Ceramic Insert |
| TSR No. | 5412T |
Tool
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Insert | RCGX120700P20015 | RCGX120700 |
| Grade | HC7 | Ceramic Coated |
Tool life
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Tool life (pcs/edge) | 2 | 1 |
Cutting conditions
| Tungaloy - NTK | Competitor | |
|---|---|---|
| Cutting speed V/c (m/min) | 549 | 549 |
| Feed f (mm/rev) | 0.38 | 0.38 |
| Depth of cut ap (mm) | 0.51 | 0.51 |
| Number of pass | 2 | 2 |
| Coolant | WET | WET |
